Esempio di comportamenti "intelligenti"

Nel caso del flocking, le regole per ogni singolo boid sono:

separazione

sterza per evitare il sovraffollamento locale

allineamento

sterza per allinearti alle traiettorie di volo dei vicini

coesione

sterza per muoverti verso la posizione media dei vicini

// height=360
// width=662 height=360
let flock;

function setup() {
//  createCanvas(662,360);
  createCanvas(windowWidth,360);
  cursor(CROSS);
//  createP("Drag the mouse to generate new boids.");

  flock = new Flock();
  // Add an initial set of boids into the system
  for (let i = 0; i < 50; i++) {
    let b = new Boid(width/2,height/2);
    flock.addBoid(b);
  }
}

function windowResized() {
    resizeCanvas(windowWidth,360);
}

function draw() {
  background(230);
  flock.run();
}

// Add a new boid into the System
function mousePressed() {
  flock.addBoid(new Boid(mouseX,mouseY));
}
function mouseDragged() {
  flock.addBoid(new Boid(mouseX,mouseY));
}

function Flock() {
  // An array for all the boids
  this.boids = []; // Initialize the array
}

Flock.prototype.run = function() {
  for (let i = 0; i < this.boids.length; i++) {
    this.boids[i].run(this.boids);  // Passing the entire list of boids to each boid individually
  }
}

Flock.prototype.addBoid = function(b) {
  this.boids.push(b);
}

function Boid(x,y) {
  this.acceleration = createVector(0,0);
  this.velocity = createVector(random(-1,1),random(-1,1));
  this.position = createVector(x,y);
  this.r = 3.0;
  this.maxspeed = 3;    // Maximum speed
  this.maxforce = 0.05; // Maximum steering force
}

Boid.prototype.run = function(boids) {
  this.flock(boids);
  this.update();
  this.borders();
  this.render();
}

Boid.prototype.applyForce = function(force) {
  // We could add mass here if we want A = F / M
  this.acceleration.add(force);
}

// We accumulate a new acceleration each time based on three rules
Boid.prototype.flock = function(boids) {
  let sep = this.separate(boids);   // Separation
  let ali = this.align(boids);      // Alignment
  let coh = this.cohesion(boids);   // Cohesion
  // Arbitrarily weight these forces
  sep.mult(1.5);
  ali.mult(1.0);
  coh.mult(1.0);
  // Add the force vectors to acceleration
  this.applyForce(sep);
  this.applyForce(ali);
  this.applyForce(coh);
}

// Method to update location
Boid.prototype.update = function() {
  // Update velocity
  this.velocity.add(this.acceleration);
  // Limit speed
  this.velocity.limit(this.maxspeed);
  this.position.add(this.velocity);
  // Reset accelertion to 0 each cycle
  this.acceleration.mult(0);
}

// A method that calculates and applies a steering force towards a target
// STEER = DESIRED MINUS VELOCITY
Boid.prototype.seek = function(target) {
  let desired = p5.Vector.sub(target,this.position);  // A vector pointing from the location to the target
  // Normalize desired and scale to maximum speed
  desired.normalize();
  desired.mult(this.maxspeed);
  // Steering = Desired minus Velocity
  let steer = p5.Vector.sub(desired,this.velocity);
  steer.limit(this.maxforce);  // Limit to maximum steering force
  return steer;
}

Boid.prototype.render = function() {
  // Draw a triangle rotated in the direction of velocity
  let theta = this.velocity.heading() + radians(90);
  fill(127,212,255);
  stroke(0,0,200);
  push();
  translate(this.position.x,this.position.y);
  rotate(theta);
  beginShape();
  vertex(0, -this.r*2);
  vertex(-this.r, this.r*2);
  vertex(this.r, this.r*2);
  endShape(CLOSE);
  pop();
}

// Wraparound
Boid.prototype.borders = function() {
  if (this.position.x < -this.r)  this.position.x = width +this.r;
  if (this.position.y < -this.r)  this.position.y = height+this.r;
  if (this.position.x > width +this.r) this.position.x = -this.r;
  if (this.position.y > height+this.r) this.position.y = -this.r;
}

// Separation
// Method checks for nearby boids and steers away
Boid.prototype.separate = function(boids) {
  let desiredseparation = 25.0;
  let steer = createVector(0,0);
  let count = 0;
  // For every boid in the system, check if it's too close
  for (let i = 0; i < boids.length; i++) {
    let d = p5.Vector.dist(this.position,boids[i].position);
    // If the distance is greater than 0 and less than an arbitrary amount (0 when you are yourself)
    if ((d > 0) && (d < desiredseparation)) {
      // Calculate vector pointing away from neighbor
      let diff = p5.Vector.sub(this.position,boids[i].position);
      diff.normalize();
      diff.div(d);        // Weight by distance
      steer.add(diff);
      count++;            // Keep track of how many
    }
  }
  // Average -- divide by how many
  if (count > 0) {
    steer.div(count);
  }

  // As long as the vector is greater than 0
  if (steer.mag() > 0) {
    // Implement Reynolds: Steering = Desired - Velocity
    steer.normalize();
    steer.mult(this.maxspeed);
    steer.sub(this.velocity);
    steer.limit(this.maxforce);
  }
  return steer;
}

// Alignment
// For every nearby boid in the system, calculate the average velocity
Boid.prototype.align = function(boids) {
  let neighbordist = 50;
  let sum = createVector(0,0);
  let count = 0;
  for (let i = 0; i < boids.length; i++) {
    let d = p5.Vector.dist(this.position,boids[i].position);
    if ((d > 0) && (d < neighbordist)) {
      sum.add(boids[i].velocity);
      count++;
    }
  }
  if (count > 0) {
    sum.div(count);
    sum.normalize();
    sum.mult(this.maxspeed);
    let steer = p5.Vector.sub(sum,this.velocity);
    steer.limit(this.maxforce);
    return steer;
  } else {
    return createVector(0,0);
  }
}

// Cohesion
// For the average location (i.e. center) of all nearby boids, calculate steering vector towards that location
Boid.prototype.cohesion = function(boids) {
  let neighbordist = 50;
  let sum = createVector(0,0);   // Start with empty vector to accumulate all locations
  let count = 0;
  for (let i = 0; i < boids.length; i++) {
    let d = p5.Vector.dist(this.position,boids[i].position);
    if ((d > 0) && (d < neighbordist)) {
      sum.add(boids[i].position); // Add location
      count++;
    }
  }
  if (count > 0) {
    sum.div(count);
    return this.seek(sum);  // Steer towards the location
  } else {
    return createVector(0,0);
  }
}

Cliccare o disegnare sul canvas per creare nuovi boid.
Il codice sorgente si può trovare fra gli esempi del sito di p5.js.

Esempio d'uso nella storia della Computer Graphics:
Larry Malone, Stanley and Stella in: Breaking the Ice, 1987
